Cage Raising Equipment for Laying Hens

Material:Surface hot dip galvanized
Function:Laying hen breeding
Specifications:1260×1300×470mm
Layers:4-12 floors
Breeding capacity:8~9 pics per door
Area of ​​each chicken:468.75cm²
Certificate:ISO9001
Production capacity:300 groups/day
Service life:20years
Method of sales:wholesale
Customized:welcome
MOQ:50 groups
Origin:China
Availability:
Quantity:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button
  • ZSCD-1200-4

  • ZEUS

  • ZSCD-001

Introduction to large stacked cages for laying hens

The large-scale stacking equipment for laying hen cages includes manure cleaning system, intermediate cage system, feeding system, drinking water system, egg collection system, and ventilation system. Environmental control systems, lighting systems.


First: Manure cleaning system: It mainly includes longitudinal manure cleaning at the bottom of the cage and horizontal and oblique manure cleaning. The advantage of our company's products is that by enlarging the steel of the manure cleaning host head, the installation stability is improved, the equipment connection is stronger, and the equipment is more stressed. Uniform, longer service life, and improved aesthetics.


Intermediate cage system: This system does not include the main frame and cage mesh. The product advantage is that reasonable and solid materials are used to ensure service life while providing good ventilation space.



We use 2.0mm thick 275g hot-dip galvanized sheets for the columns of the main frame, which are rolled into one piece with high consistency and strength; we upgraded the waterline hanging panels to 275g hot-dip galvanized sheets, which have a longer service life than plastic materials. stronger;



Between each group of cages, we use 275g hot-dip galvanized sheet K-shaped partitions to connect to the frame columns to evenly distribute the weight of the cages to avoid uneven stress and unstable service life. The wire passes through the reserved hole in the K-shaped partition. It is weighed while ensuring that the wire will not shift. Nowadays, many manufacturers use plastic materials for their K-type equipment. The overall stability is low and the service life is short. Some products are directly The K-type is removed and replaced directly with iron wire. All the weighing is concentrated on the partition wire. Often, after two or three years, the iron wire will deform or open welding due to the concentration of weight, resulting in structural instability.



We use rectangular hot-dip galvanized pipes and tensioners to fix the wire fixing points at both ends of the cage, which has strong tensile strength, instead of using two galvanized plate bending parts.



The feeding system adopts driving feeding. Our company independently develops a leveler with a feeding function, which reduces the waste of feed caused by congestion during the feeding process, increases the weight of the leveler, and makes the leveling effect better.


Fourth: The main supply of the drinking water system uses PVC40 water pipes to ensure sufficient water supply. The doser is made of French Dossier. Mechanical dosing is more energy-saving and has better effects. The tail end drainage also uses PVC40 water pipe materials to meet the simultaneous drainage of multi-layer equipment. The rear display tube is equipped with a water shortage alarm device to avoid situations that cannot be observed by humans and provide early warning.


Our company has optimized the egg-picking host in the egg-picking system and increased the egg-picking surface to 55 centimeters. The egg-picking channel is wider, which improves the efficiency of egg-picking, saves egg-picking time, and reduces dark lines on eggs caused by collisions. Eggs and broken eggs are particularly effective for high-rise equipment.



Sixth: Use a combination of negative pressure fans, cooling water curtains, side windows, and deflectors, and cooperate with the environmental controller to achieve the ideal conditions for the environs of the chicken house.

The environmental controller is used to collect and control the ventilation system, and through automatic system control, the chicken house can achieve a reasonable and good breeding environment. Make breeding environment control more stable.



Eighth: The lighting system mostly uses 48v LED bulbs, which are waterproof, safer with low voltage and more uniform illumination.
